    Dry Docking Concepts

    Dry Docking Applications for real time monitoring

    Dry Docking Concepts

    Dry Docking Applications for real time monitoring

    Dry Docking Application

    Traditional laser and radar berthing systems come with high costs and complex installations. AD Navigation offers a smarter alternative—leveraging precise RTK correction to deliver a remote, highly reliable docking solution with real-time Trim and List data for unmatched accuracy and control.

    fsru-flng

    Remote

    Remote Realtime Monitoring - Realtime monitoring from remote location

    spm

    Reliable

    Reliable Robust Design & Easy installation - fast and efficient connection, easy installation and durable

    Accurate

    RTK Accuracy - highly accurate monitor approach, RTK Speed and positioning accuracy

    System Overview

    • Real-Time Ship Position & Speed Display
      Provides continuous situational awareness throughout the dry-docking process.

    • GNSS-Based High-Accuracy Docking
      Replaces traditional laser docking with superior accuracy and reliability using GNSS positioning technology.

    • Full Vessel Attitude Monitoring
      Optional units enable real-time display of vessel position, trim, and list (port/starboard) for a comprehensive overview.

    • Dock & Block Layout Visualization
      Annotation overlays show dock and block arrangements for enhanced precision and planning.

    • 3D POD Setup for Pre-Arrival Assessment
      Visually assess vessel trim and condition prior to arrival for better preparation and alignment.

    • Real-Time Trim & List Monitoring
      Continuously monitor and display vessel trim and port/starboard list during the entire dry-docking operation.

    • QPS Navigation Software & User Interface
      Tailored interface designed specifically for dry-docking needs, offering clear, intuitive operational control.

    xr2-2pods-shadow

    XR2 Portable Pilot Unit

    • Measures Position Heading Rate of Turn and Speeds of the Shuttle Tanker relative to the FPSO
    • Sends data over UHF Link to FPSO Hawser monitoring interface option
    • Ruggedised Laptop (GETAC V110)
    • Qastor Navigation and Docking License (USB Dongle)
    • Portable ESD Pod (Optional) to initiate Emergency Shut Down (ESD) of Pumping
    • “Pelican” Case (Optional) to store and transport XR2 and Laptop
    • A single simplex UHF frequency is used, employing Time Division Multiple
    • Access (TDMA) techniques to prevent interference.
    Learn more about the XR2
    IMG_7819

    Safety

    • Enables early warning of excessive closing speeds and proximity during approach and during operations

    • Riser monitoring options

    • Remote hawser tension monitoring and emergency shut down options

    IMG_2723

    Efficiency

    • Supports Mooring Masters during approach with real time reliable relative HDG ROT COG SOG

    • Allows efficient reconnection of turret in the event a disconnect is required

    sohar_port_freezone_eng_pms

    "The service and support from AD Navigation is exceptional!"

    - Capt Umar Habib

    Chief Pilot, Port of Sohar

    We will be happy to discuss the XR2 and Dry Docking Application

    Please contact us using the form below
